EPD170LGR Low Grain Refrigerant Dehumidifier

European 220V/50 Hz 580W 2.6A(R290 refrigerant) or North American 110V/60 Hz 720W 6.5A (R410a refrigerant) alternatives.  Floor standing on 4 feet with 2 wheels and drag folding handle. Stackable refrigerant dehumidifiers rotor moulded plastic casing with electronic controls.  Side air outlet can be ducted to focus dry air  Over 170 Pints / 95 litres maximum extraction at maximum temperatures and humidity.  Power rated at (Operating range from 4°C/40°F up 38°C/100°F.  Integral pump with  maximum  water height 11ft / 3.5m.  One fan speed with 420 m3/hr / 247 cfm air volume capacity. Sound rated at 55dB. Hose length 40ft / 12m cord length 25ft / 5m

install dehumidifiers dehumidifiers by Ecor Pro
dehumidifier download user manual dehumidifiers by Ecor Pro

WATER CONDENSATE PRODUCED.WATER IS PUMPED AWAY

Ideal for Restoration Industry & Construction Industry

95 Litre / 170 Pint Low Grain Refrigerant Compressor Dehumidifier 220V / 50Hz & 110V 60Hz versions

Integral pump lifting water to 3.5m / 11ft

Free Standing. Can be stacked. Folding drag handle

Will dry 247 and dry up to 38°C/100°F.  Will stop working at 4°C / 40°F. Used in a wide variety of commercial applications where temperatures are likely to be over 25°C / 77°C. Especially designed for flood applications and drying building work, paint or plaster quicker.Very easy to access the internal parts for any service needed. Comes with drainage hose 40ft / 12m long that push fits onto the protected spigot.  Easy to plug / unplug the power cord for easy storage or to replace the power cord if damaged

Rotor Moulded Plastic Construction

Electronic controls are accessible from the front. Measures run time and amps used for easy calculation of energy costs.  EU versions come with 220 commercial water resistant plug.  North American models come with standard domestic plug.Energy efficient with optimum compressor operating times based on an internal microprocessor calculation to optimize performance.One easy connect drain hole with screw tread for secure connection

Side Dry Air Out for Focus Drying

Allows focus drying in tented areas with ducting.  Perfect to save energy costs and faster drying times.

Parts Associated

Features Explained

Extraction – R410a Version North America 110V 60Hz170 pints/day (95 0F RH95%)
135 pints/day (86 0F RH80%)80 pints/day (80 0F RH60%)
Extraction – R290a Version Europe 220V 50Hz80 L/day (35 0C RH95%)55 L/day (30 0C RH80%)35 L/day (27 0C RH60%)
Wire Mesh & Carbon Filter – In tough aluminium extrusion outer filter frame that is lockable in position with small screw driver.  Easy to clean and durable.
Easy Repair – Side panels and top cover easily remove to gain full access to the drain tray and water pump and other electrical parts for repair and maintenance
On Four Grey Rubber Feet and Two Wheels for Easy Dragging – Low profile feel that air stacking and ensure stability but will not interfere with dragging the unit over uneven floors or up steps.
One Fan Speed – The fan setting fixed for maximum performance.  420 m3/hr / 247 cfm air volume capacity
Power Supply – 220V 50Hz also  version or 110V/60Hz
Auto Reset – If there is an interruption to the power supply, the dehumidifier will resume automatically No humidistat option
Drainage – Pump drained through a standard push fit connector.  One and off in a few seconds.  Recessed so less chance of damage in transport. Water pump can pump to a height of 40ft / 12m. Used with 0.25″ / 7mm hose pipe.5m / 25′ Power Cord – Easy to replace kettle lead power cord for easy transportation and changing i the power cord becomes damaged.  European version come with commercial plug.  North American versions come with standard domestic plug
Weight 29 kg
Dimensions 34.5 × 45 × 56.0 cm
(L x W x H)-(weight)

560mm x 345mm x 450mm – 29 kg
14.7" x 31.5" x 19.6" – 66 lbs

Technology

Low Grain Refrigerant / Compressor

Max Extract

80 Litres / 170 pints

Power / Plug / Cord length

25' / 5m

Colour / Material

Dark Grey / Yellow Moulded Plastic

Duct Sizes

Adaptor provided for inputting adding 125mm / 5" duct

Swimming Pool Ready

No

Humidistat Inside / Humidistat Option

YES / YES

Carrying Handle / Water Container / Power Cord Length

2 grip points each side / No / 15' / 5m

Fan Speeds / Sound

1 / 55dB

Operting Temperature

Plus 4°C/39°F to plus 38°C/100°F

Power Out Restart / Works From DC-AC Coverter

Yes / No

Airflow m3/hr - cfm

420 – 247

Material

Rotational Moulded Polyethylene & Polypropylene mix

Approval

CE, ETL, CETL, GS, RoHS
